Text excerpt from page 21 (click to view)
PRESET FOR USE
PRESET FOR USE
The first time you may want to select language (English or Espanol=Spanish) and preset the tuner to scan only the channels you receive in your area. You must use the remote control for the following steps.
NOTE: Channel memory programming is not needed when using a converter/descrambler box.
PRESET FOR THE FIRST TIME
1 Connect the TV/VCR power cord Plug the TV/VCR power cord into a standard AC outlet. 2 Turn on the TV/VCR Press the POWER button to turn on the TV/VCR. 3 Select "ENGLISH" or "ESPANOL"
Select "ENGLISH" or "ESPANOL=Spanish" using CH button. "[ ]" marks indicate the selected language. 4 Begin auto preset Press MENU button to point to "AUTO PRESET"
or
button or SELECT
Then press SELECT button. The tuner scans and memorizes in the active channels in your area.
NOTES: • The TV/VCR distinguishes between standard TV channels and CATV automatically. • If you want to play or record a video tape BEFORE presetting the tuner, you must press MENU button. To preset the tuner again, see "AUTO PRESET AGAIN".
5 After scanning The tuner stops on the lowest memorized channel. (TV mode: from CH 02/ CATV mode: from CH 01) You may want to recall the selected channels, you can select the desired channel directly with the remote control number button or CH or .
TO RETURN TO TV MODE WHEN SCANNING
Press MENU button in scanning mode.
