TUNER & IF BLOCK
A/V BOARD 6-layer SC1_V_OUT SC3_V_OUT
I2C
UV1316 Tuner 1 Philips
IF 1
PHILIP SIF IC 1 TDA9886
TUN1_CVBS TUN1_QSS1
TO TEA6415 VIDEO SWITCH TO MSP3411G AUDIO PROCESSOR FOR MAIN SOUND
I2C
UV1316 Tuner 2 Philips
IF 2
PHILIPS IF IC 2 TDA9886
TUN2_CVBS TUN2_QSS2
TO TEA6415 PIP VIDEO SWITCH TO MSP3411G AUDIO PROCESSOR FOR PIP SOUND
49
|
