REAR PANEL JACKS
Component: Y-PBPR Inputs Inputs 4 and 5 provide Y-PBPR jacks for connecting equipment with this capability, such as a DVD player or Set Top Box. You may use standard video signal for INPUT:4 and 5. NOTES: 1. Your component outputs may be labeled Y, B-Y, and R-Y. In this case, connect the components B-Y output to the TV s PB input and
the components R-Y output to the TV s PR input. 2. Your component outputs may be labeled Y-CBCR. In this case, connect the component CB output to the TV s PB input and the component CR output to the TV s PR input. 3. It may be necessary to adjust TINT to obtain optimum picture quality when using the Y-PBPR inputs. (See pages 53 and 54) 4. To ensure no copyright infringement, the MONITOR OUT output will be abnormal, when using the Y-PBPR jacks. 5. When using Y-PBPR input, only 480i signal can be viewed as a sub-picture. 6. Input 4 and 5 (Y/VIDEO) can be used for standard video input.
12
|
|
|
> |
|
