REAR PANEL JACKS
Component: Y-PBPR Inputs Inputs 1 and 2 provide Y-PBPR jacks for connecting equipment with this capability, such as a DVD player or Set Top Box. NOTES: 1. DO NOT connect standard VIDEO or S-VIDEO to Input 1 or 2 when using Y-PBPR input.
2. When using the Y-PBPR input jacks, connect your components audio output to the TV s Input 1 or 2 Left and Right Audio input jacks. If your component has a Coaxial Out or Optical Out, use these connectors in place of the standard Audio L/R output jacks. 3. Your component outputs may be labeled Y, B-Y, and R-Y. In this case, connect the components B-Y output to the TV s PB input and the components R-Y output to the TV s PR input. 4. Your component outputs may be labeled Y-CBCR. In this case, connect the component CB output to the TV s PB input and the component CR output to the TV s PR input. 5. It may be necessary to adjust TINT to obtain optimum picture quality when using the Y-PBPR inputs. (See pages 59 and 60) 6. To ensure no copyright infringement, the MONITOR OUT output will be abnormal, when using the Y-PBPR jacks. 7. When using the Y-PBPR jacks, TV will automatically change to SPLIT PIP mode. When you have Picture-in-Picture on and are viewing a Y-PBPR input, only SPLIT mode is possible. (see page 29)
Coaxial Input This jack provides high quality audio input from a Dolby Digital DVD player or HDTV Set Top Box. This input can be used for VIDEO: 1 or VIDEO: 2 audio, as selected in the THEATER-INPUT SOURCE menu. (see page 67) Optical Input This jack provides high quality audio input from a Dolby Digital DVD player or HDTV Set Top Box. Use a digital optical cable to connect your TV to a compatible device. This input can be used for VIDEO: 1 or VIDEO: 2 audio, as selected in the THEATERINPUT SOURCE menu. (see page 67)
NOTE:
This TV s optical digital input jack fully complies with the international standard governing this type of jack (IEC958), and is designed for connection to a Dolby Digital (AC-3 or PCM) DVD Player or Dolby Digital (AC-3 or PCM) HDTV Set Top Box. Older equipment, some of which is not fully compliant with IEC958, may not be compatible with the Dolby Digital bitstream. Such a connection using anything other than Dolby Digital AC-3 or PCM bitstream could create a high noise level, causing damage to your speakers.
12
|
|
|
> |
|
