4. How to reassemble the TURN TABLE. (Fig-7)
1) Push LEVER TT in the direction of �C�, and put in the TURN TABLE 5CD. (Fig-7) After reassembly, one of the TURN TABLE DISC TRAY (can be either one of the five disc trays) must be aligned with TURN TABLE 5CD. (Fig-8) That is, having no gap difference between the TURN TABLE 5CD and the TRAY 5CD. When reassembling the TURN TABLE 5CD, it is acceptable facing any CD number (1-5).
*
ALIGN
C
LEVER TT
TRAY 5CD
Fig-7
TURN TABLE 5CD
Fig-8
8
|
|
|
> |
|
