A-207
3.3 AC PRIMARY ASSY
A
TO POWER
� NOTE FOR FUSE REPLACEMENT CAUTION - FOR CONTINUED PROTECTION AGAINST RISK OF FIRE. REPLACE WITH SAME TYPE AND RATINGS ONLY.
C
AC PRIMARY ASSY AWX7113(MLXJ) AWX7115(SDXJ)
FU1 REK1023 : MLXJ type T1.25AL250V REK1030 : SDXJ type T6.3AL250V
SDXJ type
REK1023 T1.25AL250V LIVE TRANSFORMER
POWER
ASG1035
MLXJ type
B
SDXJ type
NEUTRAL REK1023 T1.25AL250V
SDXJ model
TO S2 VOLTAGE SELECTOR
TO POWER CORD
C
D
C
