SPECIFICATIONS
Main unit
Playback system Laser pickup Recording system Revolutions Sampling Frequency Number of channels Modulation system A/D, D/A converter Frequency response Wow and Flutter Input Jack type Rated input level Minimum input level Output Jack type Maximum output level Load impedance Power requirements OUTPUT / PHONES Stereo mini-jack 10 mW + 10 mW 16 ohms DC 3.6 V using the supplied lithium-ion rechargeable battery LIB�902 DC 1.5 V using one LR6 (size AA) dry cell batteries (used together with rechargeable battery) AC house current using the supplied AC adaptor AC�D401. Using the supplied rechargeable battery Approx. 11.5 hours for playback Approx. 5 hours for recording Using the supplied rechargeable battery and one LR6 (size AA) dry cell batteries Approx. 20 hours for playback Approx. 7.5 hours for recording Approx. 78.8 (W) X 18.8 (H) X 86.8 (D) mm (31/ X 3/ X 31/ inches)
8 4 2
MiniDisc digital audio system Semiconductor laser Magnetic polarity modulation overwrite system Approx. 400 to 900 rpm (CLV) 44.1 kHz, with built-in sampling frequency rate converter Stereo: 2 channels Monaural: 1 channel Eight to Fourteen Modulation (EFM) 1-bit 20 to 20,000 Hz ± 1 dB Below measurable limit (±0.00 1% W.PEAK) MIC Stereo mini-jack 1.1 mV 0.4 mV LINE Stereo mini-jack 280 mV 100 mV OPT (digital) OPTICAL mini-jack � �
Battery life
Dimensions Weight
Approx. 163 g (6 oz) including the rechargeable battery.
AC adaptor (AC�D401) Output Rated voltage
DC 4.5 V AC 230 V, 50 Hz
� Design and specifications are subject to change without notice.
ACCESSORIES / PACKAGE LIST
REF. NO. PART NO. 2 6
KANRI DESCRIPTION NO. 87-B30-144-010 AC ADAPTOR,AC-D401K NC 8A-HM1-961-010 BOX ASSY,BAT AHM-1 L
�2�
|
|
|
> |
|
