4.

Play something on the keyboard to start recording.
� What you play sounds from the speakers and is recorded into memory. � You can also start recording by pressing PLAY/STOP. In this case, blank space is inserted in memory from the point that you press PLAY/STOP up to the point you start to play on the keyboard. � The indicator lamp above the RECORD button changes from flashing to lit when recording starts.

Playback
Use the following procedure to play back from song memory.

To play back from song memory

1. 2.

Press the SONG MEMORY button.
� This causes the indicator lamp above the button to light.

5.

After you are finished recording, press PLAY/ STOP to stop the record operation.
� At this time the indicator above RECORD goes out, while the indicator above the recorded track remains on. � Here you can press PLAY/STOP and playback the data you just recorded. � To exit the song memory mode, press the SONG MEMORY so its indicator lamp goes out.

Press the TRACK button of the track you want to play back (A or B).
� This causes the indicator lamp above the button of the track you select to light.

3.

Press PLAY/STOP to start playback.
� You can toggle the playback metronome sound on and off by pressing the METRONOME button. � To stop the metronome, press the METRONOME button. � Playback stops automatically when the end of the tune is reached. � To stop part way through, press PLAY/STOP.

To record to one track while playing back from the other track
This procedure is basically the same as that under �To record notes from the keyboard� on page E-20. The differences are as described below.
Example: To play back Track A while recording to Track B

� NOTE
� If you want to playback song memory contents you have just recorded, simply press PLAY/STOP. � You cannot change the tone when playing back from song memory. � You can change the playback tempo while playing back from song memory.

� Before starting step 2 of the procedure on page E-20, press the TRACK A button so the indicator above it is lit. � When you enter record standby, the indicator above the TRACK A button remains lit, while the indicator above the TRACK B button flashes. If the indicator above the TRACK A button is flashing at this time, press the TRACK B button so the indicator above it flashes. � Performing step 4 of the procedure causes Track A play back and Track B recording to start at the same time. Play on the keyboard along with the playback of Track A. � Once you enter record standby, you can also change the tempo and beat settings. It should be noted, however, that playback is performed following the last tempo and beat settings that were used for recording in either of the tracks.
