Parts Catalog
FIGURE 1 PRINTER SET FIGURE 2
BJC-250
FRONT COVER
NUM. PART #
DESCRIPTION
NUM. PART # 2-1 2 3 4 5 6 QG5-0972-000 QB1-1952-000 QB1-1039-000 QB1-2264-000 QS5-8265-000 QB1-2948-000
DESCRIPTION FRONT COVER UNIT (WITH SPUR) SPUR SPURSHAFT LABEL, INSTALL PLATE, LOGO PLATE, MODEL NAME
1 - 1 QH3-3173-000 AC ADAPTER: 120V 60HZ OUTPUT 13VDC, 1.0A QH3-3174-000 AC ADAPTER: 220-240V 50HZ OUTPUT 13VDC, 1.0A QH3-3175-000 AC ADAPTER: 240V 50HZ, UK OUTPUT 13VDC, 1.0A QH3-3176-000 AC ADAPTER: 240V 50HZ, AUS OUTPUT 13VDC, 1.0A 2 NPN BLACK BJ CARTRIDGE PACK NPN COLOR BJ CARTRIDGE PACK NPN COLOR BJ CARTRIDGE PHOTO PACK 3 NPN BJ CARTRIDGE CONTAINER
1 of 9
|
|
|
> |
|
