There are currently no product reviews.
 ;
Exactly what was needed to assess the product - excellent value and great service
 ;
Nice to have the service manual for the Sony DCR-TRV345E now. The document is of excellent quality.
;
MACKIE HR824 26 pages English-only Service Manual contains:
1) HR824 technical overview with the description of front and rear panel switches.
2) HR824 specs
3) Block Diagram
4) Wiring Diagram
5) Packaging management
6) Spare part & final assembly list (for PCB rev A and B) + exploded view
7) Test Procedures (where, how to measure voltage...) including Test Point diagram on the PCB.
8) IC and Transistor charts.
Excellent guide: very clear, good scan quality enabling us to print readable diagram :-)
Note:
Mackie HR824 make extensive use of surface mount devices (SMD). Service on the HR824 must
only be undertaken by experienced service technicians with the right tools, experience and patience to perform surface mount rework when needed.
;
This Service manual is very well scanned and its clean to read, no any anti-theft words that un-english could understand. I got my CCD600 working with this manual and it´s clear shematics :)
;
I was very pleased with the service provided and was surprised at how good the quality was of the manual. I thought it may be a third generation copy or so, but it is as good as the websites that charge 3 times this much. I repair some electronics for family and friends without charge, so this is perfect for me. Thank you very much.
BJC-5000
Part 5: Maintenance
7.Machine Temperature Error
<Cause> The thermistor is abnormal. <Suspected Parts> Thermistor <Corrective Action> Replace the logic board.
8.Waste Ink-Full Warning/Error
<Corrective Action>
Visual check of the waste ink absorber
<Cause> The waste ink absorbers� estimated waste ink amount
has reached 95% (Warning) or 100% (Error). <Suspected Parts> Waste ink absorbers, logic board
� Check to see how much ink the waste ink absorber has absorbed. (Check the rate of ink penetration for the entire waste ink absorber as a guideline to determine the waste ink counter setting value.) No 1. Reset the waste ink amount in the EEPROM. 2. Replace the logic board. 0% (clear), 25%, 50% or 75% (See Part 3 �3.4 Service Mode.)
Waste ink absorbed is 75 % or more of the limit ? Yes
Replace the waste ink absorber. END
� Clear the total of the waste ink amount saved in the EEPROM.
5-21
|
|
|
> |
|
|
