CHAPTER 3. MECHANICAL SYSTEM
III. PURGE UNIT
CAUTION � Do not touch the wiper or caps. � Since waste ink accumulates on the bottom of the purge unit, hold the sides of the purge unit when removing it. � Be careful not to spill the waste ink.
4) Cap the pipe [2] and the end of the waste ink tube [2] using the waste ink tube caps [3].
[2]
1. Removing the purge unit 1) Remove the right cover (See page 3-7). 2) Open the front cover, and holding the green part, move the carriage to the center. 3) Remove the tube clamp [1] and disconnect the waste ink tube from the pipe [2].
[3]
[2]
Figure 3-302
[3]
[1]
[2]
Figure 3-301
3�21
|
|
|
> |
|
