MACKIE HR824 26 pages English-only Service Manual contains:
1) HR824 technical overview with the description of front and rear panel switches.
2) HR824 specs
3) Block Diagram
4) Wiring Diagram
5) Packaging management
6) Spare part & final assembly list (for PCB rev A and B) + exploded view
7) Test Procedures (where, how to measure voltage...) including Test Point diagram on the PCB.
8) IC and Transistor charts.
Excellent guide: very clear, good scan quality enabling us to print readable diagram :-)
Note:
Mackie HR824 make extensive use of surface mount devices (SMD). Service on the HR824 must
only be undertaken by experienced service technicians with the right tools, experience and patience to perform surface mount rework when needed.
;
This Service manual is very well scanned and its clean to read, no any anti-theft words that un-english could understand. I got my CCD600 working with this manual and it´s clear shematics :)
;
I was very pleased with the service provided and was surprised at how good the quality was of the manual. I thought it may be a third generation copy or so, but it is as good as the websites that charge 3 times this much. I repair some electronics for family and friends without charge, so this is perfect for me. Thank you very much.
2-9. Cleaning 2-10. Use of Extension Board EX-351
2-9. Cleaning
The temperature in the unit increases when dust attaches to the filter and when the air flow is disturbed. This will badly influence the performance and life of the unit. Be sure to clean the filter with attached to the front panel when the filter is clogged with dust. n � Turn off the power before cleaning the filter. � Be sure to remove the air filter from the front panel before cleaning. Tools
2-10. Use of Extension Board EX-351
Extension Board EX-351 : Part No. J-6185-310-A Extension board EX-351 is applicable for the following plug-in boards to be inspected.
Model Name BVS-A3232
Card Board CPU-94 MX-82
BKDS-RS1690
CPU-94
Procedure Vacuum cleaner 1. Remove the plug-in board in the procedure as shown Cleaning 1. Remove the front panel. (Refer to �2-1. Removal of Cabinet�.) 2. Remove the filter from the front panel. in Section 1-7 �Optional Board Installation�. 2. Move the board lever in the direction of the arrow and insert completely the extension board along the board guide rail.
Board guide rail
Filter Board lever
Extension board (EX-351)
3. Remove the dust on the filter using a vacuum cleaner. 4. Attach the filter in the reverse order of steps 1 to 2.
Board lever
BVS-A3232
2-7(E)
|
|
|
> |
|
