BM-21/23
1-5. MECHANISM DECK (MB-23-101)
3 two screws (M1.4 � 3.0)
1 Remove the soldering.
lock plate assembly
2 Set the holder panel assembly to eject.
A
shaft-A
4 mechanism deck (MB-23-101)
note : When attaching the mechanism deck, set the mechanism deck to stop and adjust the position of shaft-A and part A of the lock plate assembly.
1-6. HOLDER PANEL ASSEMBLY
4 holder panel assembly
claw
A 2 Move the battery coil spring in the direction of the arrow and secure it with the screw.
claw
A
3 two screws (M1.4 � 1.6) 1 While pressing the button (eject), insert the two claws of the holder panel assembly into the holes indicated by arrows A.
7
 $4.99 BM-23 SONY
Owner's Manual Complete owner's manual in digital format. The manual will be available for download as PDF file aft…
|
