2-11. Replacement of DC/DC Convertor Unit
2-11. Replacement of DC/DC Convertor Unit
1. Remove the right and left side panels of the camera. (Refer to �2-2. Removal of Cabinet�.) 2. Remove the two screws on the left side of the camera shown in the figure.
3. Thread the two screws that were removed in Step 2, into the holes of the DC/DC convertor unit three turns. n Never turn the two screws more than three turns. 4. Hold the two screws with hands and remove the DC/ DC convertor unit.
DC/DC Convertor Unit
B2.6 X 5
5. Install a new DC/DC convertor unit pushing with hands. Secure it to the MB-602 board with the two screws that were removed in Step 2.
BVP-550
2-15 (E)
|
|
|
> |
|
