MACKIE HR824 26 pages English-only Service Manual contains:
1) HR824 technical overview with the description of front and rear panel switches.
2) HR824 specs
3) Block Diagram
4) Wiring Diagram
5) Packaging management
6) Spare part & final assembly list (for PCB rev A and B) + exploded view
7) Test Procedures (where, how to measure voltage...) including Test Point diagram on the PCB.
8) IC and Transistor charts.
Excellent guide: very clear, good scan quality enabling us to print readable diagram :-)
Note:
Mackie HR824 make extensive use of surface mount devices (SMD). Service on the HR824 must
only be undertaken by experienced service technicians with the right tools, experience and patience to perform surface mount rework when needed.
;
This Service manual is very well scanned and its clean to read, no any anti-theft words that un-english could understand. I got my CCD600 working with this manual and it´s clear shematics :)
;
I was very pleased with the service provided and was surprised at how good the quality was of the manual. I thought it may be a third generation copy or so, but it is as good as the websites that charge 3 times this much. I repair some electronics for family and friends without charge, so this is perfect for me. Thank you very much.
;
The service was great and the document was also great. Highly recommend!!!!
If anyone has a users manual... Please email me. need one. $ [email protected]
;
I needed a service manual as the display on my oscilloscope was very dim. I thought I'd give owner-manuals.com a try, as they advertised a huge number of manuals. Sure enough they had one listed. I bought it hoping it would be useful... actually, I bought it hoping it would be readable! I've had manuals from online sources in the past, and been very disappointed. Not this time! An excellent manual, complete, and very readable. Using it I fixed my 'scope, and as such the manual was an investment that paid off manyfold. Do I have any complaints? One very minor one - The circuit diagrams could have been scanned at a higher resolution, as some of the details were a little difficult to make out - not impossible, just not as easy as my old eyes would like! Overall, I'm very satisfied with my manual, and I will certainly be using this company again. Well done.
PJ-TX10 (C10H)
6-7 The Air filter
The air filter should be cleaned about every 100 hours. If the indicators or a message prompts you to clean the air filter, clean the air filter as soon as possible. If the air filter becomes clogged by dust or the like, internal temperature rises and could cause malfunction.
WARNING � Please carefully read the "User�s Manual - Safety Guide".
� Before replacing the air �lter, make sure the power switch is off and the power cable is not plugged in. � Use the air �lter of the speci�ed type only. Type number: NJ08312 � Do not use the projector with the air �lter and �lter cover removed. The use without the air �lter could result in damage.
CAUTION � Do not reset the filter timer without cleaning or replacing the air filter.
� If the air �lter becomes clogged by dust or the like, internal temperature rises and could cause malfunction. The power is automatically turned off in order to prevent the projector from overheating internally. � When you replace the lamp, please replace also the air �lter. The air �lter may be attached to the replacement lamp. Caring For The Air filter 1. Turn off the projector, and unplug the power cord. 2. After making sure that the projector has cooled adequately, remove the filter cover. 3. Clean the air filter with a vacuum cleaner. 4. Install the air filter and the filter cover. 5. Reset the filter timer, according to following "Reset The Filter Timer". (1) Turn on the projector. While the projector running, press the MENU button to open the menu. (2) Choose the "OPTION" on the menu using the / button, then press the button or ENTER button. (3) Choose the "FILTER TIME" using the / button, then press and hold the
Air Filter
Filter Cover
button of projector or the RESET button of remote control for 3 seconds. (4) Choose the "RESET" using the button. Replacing The Air Filter If the soiling will not come off the air filter, or it becomes damaged, then it needs to be replaced. Please replace the air filter as soon as possible. Filter cover 1. Turn off the projector, and unplug the power cord. 2. After making sure that the projector has cooled adequately, remove the filter cover. Hold the release buttons of the filter cover, while pulling up it. 3. Hold the release buttons of the air filter, while pulling down it. 4. Insert a new air filter, and replace the filter cover. Release buttons 5. Reset the filter timer, according to following "Reset The Filter Timer". (1) Turn on the projector. While the projector running, press the MENU button to open the menu. Release buttons (2) Choose the "OPTION" on the menu using the / button, then press the button or ENTER button. (3) Choose the "FILTER TIME" using the / button, then press and hold the
Air filter
button of projector or the RESET button of remote control for 3 seconds. (4) Choose the "RESET" using the button.
