17. DISASSEMBLY PROCEDURE
1. Remove the battery cover, batteries and ink ribbon cassette. 2. Loosen 9 screws ¬ on the lower case ®, and open the lower case. 3. Remove 6 wires from the buzzer � and battery terminals with the help of fusing these welds. 4. Take out the connectors CN3 and CN4 on the PCB-1 ass�y 1, and loosen 3 screws x on the PCB1 ass�y. 5. Take the FPC tape of chassis ass�y D away from PCB-1 ass�y 1, and loosen 2 screws | on the PCB-1 ass�y 1. 6. Loosen 10 screws | on the PCB-E4 ass�y 4, 2 screws | on the LC holder 0. Then remove the PCB-1 ass�y 1 and the PCB-E4 ass�y 4 from the upper case t. 7. Loosen 3 screws x on the chassis ass�y D and take the chassis ass�y away from the upper case t. 8. Take out the spring I and remove the tape holder ]. 9. Loosen 2 screws W on the scissors sub ass�y G, and take out the spring J. Then remove the scissors sub ass�y G. 10. Loosen 4 screws x on the dial holder b, and take out the dial elements.
� 31 �
|
|
|
> |
|
