Probably it never existed a 1081 official service manual from Commodore, it's look more like a NAPCEC service manual & diagrams compilation of the 1084 series and his variants, like the nap6523, 8cm505, 1084S, 1084P and obviously the 1081. It's more complete than other scans and the quality of the scans also are far superior. It has two circuit diagrams variants of the 1081, mono and stereo versions. It doesn't include a diagram for the Philips CM8500 or CM8501, they look like the 1081 but they are slightly different.
4. SERVICE MODE AND EMERGENCY DISC EJECT
SERVICE MODE 1. Insert mains cable plug in the outlet and press POWER button. 2. Press the OPEN/CLOSE button to open the tray. 3. Press the TIME button for about �ve seconds. 4. The version number of the microprocessor is displayed Ex: 03-27-01. 5. Press the EDIT button for about �ve seconds. 6. Light up all the FL segment. Turn off power to quit Service mode.
EMERGENCY DISC EJECT 1. Remove the top cover of the plyer. 2. Remove 2 screws under the label shown in the picture follows. 3. Remove the disc clamper. 4. Now you can remove the disc.
Remove those screws
