Local mode
Local mode allows you to tune in only to strong stations during Seek Tuning. 1 Press LO before you start seek tuning. �LO� appears in the display. To return to Distant mode, press LO again. �LO� disappears and the unit tunes in to all receivable stations.
Presetting stations manually
(Manual Memory)
1 Press FNC repeatedly to select the desired band
(FM1, FM2, FM3, AM1 or AM2).
2 Press TUNEi or TUNEk to tune in to a desired
station (see �Tuning in to a station,� page 3).
3 Press the desired preset station button until the unit
beeps.
Using preset stations
You must preset stations before you can tune in a station using preset station number buttons.
Note
A newly preset station replaces the station on the same band that was previously stored on that preset station button.
Tuning in to a preset station
1 Press FNC repeatedly to select the desired band
(FM1, FM2, FM3, AM1 or AM2).
2 Press the preset station button on which the desired
Preset station buttons 1 ~ 6 station is stored.
Active tuning reception control (ATRC)
The unit automatically suppresses FM noise caused by vehicle movement, and maintains sound quality.
Preset station number
Using the timer
(My Information)
You can schedule the radio to activate for daily radio programs. The unit automatically turns on and off in Radio mode at the scheduled times.
Presetting stations automatically
(Auto Memory)
1 Press FNC repeatedly to select the desired band
(FM1, FM2, FM3, AM1 or AM2).
2 Press and hold PS/A.ME until automatic presetting
starts. The unit automatically stores up to 6 stations for each band. After completion of automatic presetting, the unit tunes in to the station stored on preset station button 1. To cancel automatic presetting, press PS/A.ME again.
Smart Jog
MY INFO indicator
Setting the timer
1 Turn off the unit. 2 Press and hold INFO until �PO� flashes in the
display.
Checking the preset stations (Preset Scan)
1 Press PS/A.ME briefly.
Each preset station will be tuned in for 5 seconds in order. To cancel Preset Scan, press PS/A.ME again or any preset station button.
3 Press SEL. 4 Set the time you wish the unit to turn on.
� Press TUNEi and turn the Smart Jog to set the hour. � Press TUNEk and turn the Smart Jog to set the minute. 5 Press SEL. 6 Press FNC to select the band. 7 Press TUNEi, TUNEk or the desired preset station button to select the station. 8 Press SEL. 9 Set the time you wish the unit to turn off following the same procedure used in step 4.
ENGLISH
4
 $4.99 CDCX217 AIWA
Owner's Manual Complete owner's manual in digital format. The manual will be available for download as PDF file aft…
|
|
|
> |
|
