Deutsch
Technische Daten
UKW-TEIL
Empfangsbereich ..................................................... 87,5 bis 108,0 MHz Mono-Nutzempfindlichkeit ............................................................ 0,7 µV Geräuschberuhigung, 50 dB ......................................................... 1,1 µV Ausweichkanaltrennschärfe ........................................................... 80 dB Störabstand ................................................................................... 65 dB Stereotrennung .............................................................................. 35 dB
FERNBEDIENUNG (nur CDM-7837R)
Batterien ... ....................................... R03-Trockenzellen (Grö�e "AAA") Anzahl Batterien ... .............................................................................. 2 Abmessungen (B � H � T) ... ..................................... 56 � 14 � 105 mm Gewicht (ohne Batterien) ... .............................................................. 50 g
ALLGEMEINES
Spannungsversorgung ... 14,4 V Gleichspannung (11 bis 16 V zulässig) Max. Ausgangsleistung CDM-7837R ....................................................................... 40 W � 4 CDM-7834R ....................................................................... 35 W � 4 Output Spannung ....................................................... 500 mV/10k ohms Tiefenregelung ............................................................. ±15 dB bei 30 Hz Höhenregelung .......................................................... ±10 dB bei 10 kHz Gewicht ......................................................................................... 1,5 kg
MW-TEIL
Empfangsbereich ........................................................ 531 bis 1.602 kHz Empfindlichkeit (IEC-Standard) ........................................ 25,1 µV/28 dB
LW-TEIL
Empfangsbereich ........................................................... 153 bis 281 kHz Empfindlichkeit (IEC-Standard) ........................................ 31,6 µV/30 dB
CD-TEIL
Frequenzgang ...................................................... 5 � 20.000 Hz (±1 dB) Gleichlaufschwankungen (% WRMS) ............................... Nicht me�bar Gesamtklirrfaktor ...................................................... 0,008% (bei 1 kHz) Dynamikumfang ........................................................... 95 dB (bei 1 kHz) Rauschabstand .............................................................................. 95 dB Kanaltrennung ............................................................. 85 dB (bei 1 kHz)
EINBAUMASSE
Breite .......................................................................................... 178 mm Höhe ............................................................................................ 50 mm Tiefe ........................................................................................... 153 mm
FRONTPARTIE
Breite .......................................................................................... 170 mm Höhe ............................................................................................ 46 mm Tiefe ............................................................................................. 18 mm Hinweis: �nderungen der technischen Daten und des Designs zum Zwecke der Verbesserung vorbehalten.
59
|
|
|
> |
|
