7. GENERAL INFORMATION
7.1 DIAGNOSIS
A
7.1.1 DISASSEMBLY
- Removing the Case (Fig.1) Case
1
Remove the four screws and then remove the Case.
1
1
B
1
1
Fig.1
- Removing the Mother Unit (Fig.2)
C
1
Straighten the tabs at three locations indicated. Remove the Mother Unit.
1
1
D
1
Mother Unit
Fig.2
E
F
26
CD-UB100/XN/UC
