SAFETY NOTICE
SAFETY PRECAUTION
1: An isolation transformer should be connected in the power line between the receiver and the AC line when a service is performed on the primary of the converter transformer of the set. 2: Comply with all caution and safety-related notes provided on the cabinet back, inside the cabinet, on the chassis or the picture tube. 3: When replacing a chassis in the cabinet, always be certain that all the protective devices are installed properly, such as, control knobs, adjustment covers or shields, barriers, isolation resistor-capacitor networks etc.Before returning any television to the customer, the service technician must be sure that it is completely safe to operate without danger of electrical shock.
X-RADIATION PRECAUTION
The primary source of X-RADIATION in the television receiver is the picture tube. The picture tube is specially constructed to limit X-RADIATION emissions. For continued X-RADIATION protection, the replacement tube must be the same type as the original including suffix letter. Excessive high voltage may produce potentially hazardous X-RADIATION. To avoid such hazards, the high voltage must be maintained within specified limit. Refer to this service manual, high voltage adjustment for specific high voltage limit. If high voltage exceeds specified limits, take necessary corrective action. Carefully check +B1 volt power supply, and and that the high voltage is within the specified limits.
PRODUCT SAFETY NOTICE
Product safety should be considered when a component replacement is made in any area of a receiver. Components indicated by mark / !\ in the parts list and the schematic diagram designate components in which safety can be of special significance. It is particularly recommended that only parts designated on the parts list in this manual be used for component replacement designated by mark /!\ . No deviations from resistance wattage or voltage ratings may be made for replacement items designated by mark /!\ .
SPECIFICATIONS
Specifications Power source Television system Colour system Receiving channel (CE28WP2-B) AC 220~240V 50Hz System I PAL VHF E2~E12 UHF 21~69 CATV S1~S41, X,Y,Z 75ohm CENELEC standard<RGB/,S-in> CENELEC standard RCA type,Video,Audio-L/R input 10 watts X2 12 watts X1 6 watts X 2 70cm diagonal, 106 degree 66cm 739 x 494 x 485 mm 38.5 Kg -2F2JA/KB
Aerial input impedance AV terminal 21 Pin socket AV1 AV2 Front AV terminal AV3 Sound output Main (Continuous) Centre Rear Picture tube (Visible picture diagonal) Dimensions (WxHxD) Weight
(CE32WP2-B) <-<-<-<-<-<-<-<-<-<-<-<-<-80cm diagonal, 106 degree 76cm 853 x 557 x 540 mm 50.8 Kg
|
|
 |
> |
|
