2.7.4 Power Management 2.7.4.1 Meet VESA DPMS proposal
The monitor must comply with the Microsoft On Now specification, with a minimum of three power management states, as defined by the VESA DPMS document. The front panel of the monitor must appropriately display the DPMS state, For example:
DPMS ON : DPMS OFF : 2.7.5 Power Consumption
On mode Off mode DC power off disconnection
The power LED is Green The power LED is Amber
40Wmax (EP878) 48Wmax (EP877) 3Wmax 3Wmax 3Wmax
Green Amber Dark Dark (DC power off) Amber (DC power on)
Power saving states are measured with speakers attached but not worked. The recovery time from stand by /suspend/off mode to on mode is 3 seconds maximun. 2.7.6 Power Connector
All units shall have an IEC/CEE-22 type male power receptacle.
2.8 Plug & Play (EDID)
The monitor will be capable of sending a VESA standardized EDID file through the DDC (pins 12, 15 of the VGA connector).
