CMT-CP11/CP11K
SERVICE MANUAL
� CMT-CP11/CP11K are composed of following models. As for the service manual, it is issued for each component model, then, please refer to them.
US Model Canadian Model AEP Model UK Model E Model Australian Model
CMT-CP11
E Model
COMPONENT MODEL NAME
CMT-CP11/CP11K COMPACT DISC DECK RECEIVER SYSTEM SPEAKER SYSTEM HCD-CP11 SS-CCP11 � Abbreviation AED : North European model CND : Canadian model TW : Taiwan model EA : Saudi Arabia model AR : Argentine model MX : Mexican model SP TH KR MY AUS HK
CMT-CP11K
: Singapore model : Thai model : Korea model : Malaysia model : Australian model : Hong Kong model
SPECIFICATIONS
General Power requirements North American model: European model: Australian model: Mexican model: Other models: 120 V AC, 60 Hz 230 V AC, 50/60 Hz 220-240 V AC, 50/60 Hz 120 V AC, 60 Hz 110-120 V or 220-240V AC, 50/60 Hz Adjustable with voltageselector. 70 W Approx. 190 x 252 x 310 mm incl. projecting parts and controls. Approx. 5.6 kg Remote Commander (1) AM loop antenna (1) FM lead antenna (1) Batteries (2)
PARTS LIST
Part No. Description Remark ACCESSORIES & PACKING MATERIALS ******************************** COMMANDER, STANDARD (RM-SCP1) ANTENNA, LOOP ANTENNA (FM)(E, AR, TW, KR, US, CND, SP, MY, EA, HK, TH) ANTENNA (FM)(AED, AEP, UK, CIS) ADAPTOR, CONVERSION 2P (TW, SP, MY, AUS, KR, TH) MANUAL, INSTRUCTION (ENGLISH)(EXCEPT AED, KR, TH) MANUAL, INSTRUCTION (FRENCH)(US, CND, EA) MANUAL, INSTRUCTION (SPANISH)(AR, MX) MANUAL, INSTRUCTION (FRENCH, SPANISH)(AEP, E, SP, MY) MANUAL, INSTRUCTION (GERMAN)(AEP) MANUAL, INSTRUCTION (DUTCH, ITALIAN, PORTUGUESE)(AEP) MANUAL, INSTRUCTION (DANISH, FINNISH, SWEDISH)(AED) MANUAL, INSTRUCTION (RUSSIAN, POLISH)(CIS) MANUAL, INSTRUCTION (ARABIC)(EA) MANUAL, INSTRUCTION (CHINESE)(SP, MY, HK, TW)
1-418-299-11 1-501-374-11 1-501-659-61 1-754-060-11 1-569-008-21 4-227-681-11 4-227-681-21 4-227-681-31 4-227-681-41 4-227-681-51 4-227-681-61 4-227-681-71 4-227-681-81 4-227-681-91 4-227-734-11
Power consumption Dimensions (w/h/d)
Mass: Supplied accessories:
Design and specifications are subject to change without notice.
4-227-735-31 MANUAL, INSTRUCTION (TURKISH)(CIS) 4-227-735-41 MANUAL, INSTRUCTION (GREEK)(CIS) 4-991-151-01 COVER, BATTERY (RM-SCP1)
MICRO HiFi COMPONENT SYSTEM
Sony Corporation
9-929-094-11
Home Audio Division Company
2000C001685-1 Printed in Japan ©2000.3 Published by Quality Assurance Dept.
|
|
 |
> |
|
