MECHANICAL MAIN PARTS LIST
REF. NO 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
KANRI DESCRIPTION NO. S0-801-180-100 LENS,DIAL S0-101-460-100 CAB,FRONT S0-503-380-000 KNOB,RTRY TUN S1-700-780-000 GEAR,TUNING ABS S0-700-420-000 POINTER S1-010-020-000 S0-503-360-000 S0-901-160-000 S1-010-012-400 S0-503-370-000 S0-201-870-000 S0-201-450-100 S0-301-440-000 S0-100-050-000 S2-010-012-301 SLIM MYLAR SKR 57MM 0.2W 4OHM KNOB,RTRY VOL HOLDER,BAR PE AM BAR ANTENNA SET 10-50 KNOB,SL BAND BATT CONTACT(-) CAB,REAR DOOR,BATT HAND STRAP(BLK) FM ROD ANT 5 SECTION PAN-WASHER S-SCREW M2-4(T) PAN M-SCREW M1.7-3 PAN S-SCREW(B) M2.6-6
PART NO.
A 87-254-033-410 B 87-268-527-310 C 87-261-073-410
COLOR NAME TABLE
Basic color symbol Color Basic color symbol Color Basic color symbol Color B Black C Cream D Orange G Green H Gray L Blue LT Transparent Blue N Gold P Pink R Red S Silver ST Titan Silver T Brown V Violet W White WT Transparent White Y Yellow YT Transparent Yellow LM Metallic Blue LL Light Blue GT Transparent Green LD Dark Blue DT Transparent Orange
