ADJUSTMENT
<TUNER SECTION> 1. AM IF Adjustment Settings : Test Point IC2(TA2022AFN)22PIN Adjustment Location : T2 T2�����������..450KHz FM IF Adjustment Settings : Test Point IC2(TA2022AFN)22PIN Adjustment Location : T1 T1�����������.10.7MHz AM Frequency Range Adjustment Settings : Test Point IC2(TA2022AFN)22PIN Adjustment Location : L4 TC4 L4�����������.515+/-5KHz TC4����������.1635+/-30KHz AM Tracking Adjustment Settings : Test Point IC2(TA2022AFN)22PIN Adjustment Location : L3 TC3 L3�����������.600KHz TC3����������.1400KHz 5. FM Frequency Range Adjustment Settings : Test Point IC2(TA2022AFN)22PIN Adjustment Location : L2 TC2 L2�����������.87.4+0.1/-0.2MHz TC2����������.108.3+0.2/-0.2MHz 6. FM Tracking Adjustment Settings : Test Point IC2(TA2022AFN)22PIN Adjustment Location : L1 TC1 L1�����������.88MHz TC1����������.108MHz 7. VCO Adjustment Settings : Test Point IC(TA2022AFN)22PIN Adjustment Location : VR2 VR2����������.19KHz
2.
`
3.
4.
� 10 �
|
|
|
> |
|
