ALTERATION LIST
MECHANICAL PARTS LIST 1/1
REF. NO 1 3 4 5 7 18 31 32 33
KANRI DESCRIPTION NO. 8Z-CS8-088-010 WINDOW,CASS (S BLUE) 8Z-CS8-083-010 BOX,CASS (S BLUE) 8Z-CS8-086-010 GRILLE,SP L (S BLUE) 8Z-CS8-087-010 GRILLE,SP R (S BLUE) 8Z-CS8-090-010 CABI,FR EX (S BLUE) 8Z-CS8-089-010 8Z-CS8-091-010 8Z-CS8-085-010 8Z-CS8-084-010 KNOB,RTRY VOL (S BLUE) CABI,REAR EX (S BLUE) HANDL,(S BLUE) LID,BATT (S BLUE)
PART NO.
COLOR NAME TABLE
Basic color symbol Color Basic color symbol Color Basic color symbol Color B Black C Cream D Orange G Green H Gray L Blue LT Transparent Blue N Gold P Pink R Red S Silver ST Titan Silver T Brown V Violet W White WT Transparent White Y Yellow YT Transparent Yellow LM Metallic Blue LL Light Blue GT Transparent Green LD Dark Blue DT Transparent Orange
2�11, IKENOHATA 1�CHOME, TAITO-KU, TOKYO 110-8710, JAPAN TEL:03 (3827) 3111
931196 Printed in Singapore
|
|
|
> |
|
