Radio Operation
Manual Storing of Station Presets
3
1 2 3
Select the radio band and tune in a desired radio station you wish to store in the preset memory. Press and hold any one of the Preset buttons (1 through 6) for at least 2 seconds until the station frequency (sub display) or preset number (monitor display) on the display blinks. Press the Preset button into which you wish to store the station while the frequency (sub display) or preset number (monitor display) is blinking (within 5 seconds). The display stops blinking once the station has been memorized. The display shows the band, preset No. with a triangle (9*) and station frequency memorized. * displayed in sub display
Press and hold the A. ME button for at least 2 seconds. The frequency on the display continues to change while the automatic memory is in progress. The tuner will automatically seek and store 6 strong stations in the selected band. They will be stored into presets 1 to 6 buttons in order of signal strength. When the automatic memory has been completed, the tuner goes to the station stored in the preset location No. 1. NOTE
If no stations are stored, the tuner will return to the original station you were listening to before the auto memory procedure began.
Tuning to Preset Stations
1 2 3
Press the SOURCE button to select the radio mode. Press the BAND button repeatedly until the desired band is displayed. Press the station Preset button that has your desired radio station in memory. The display shows the band, preset number with a triangle and frequency of the station selected.
4
Repeat the procedure to store up to 5 other stations onto the same band. To use this procedure for other bands, simply select the band desired and repeat the procedure. A total of 30 stations can be stored in the preset memory (6 stations for each band; FM1, FM2, FM3, MW or LW.)
NOTE If you store a station in a preset memory which already has a station, the current station will be cleared and replaced with the new station.
Automatic Memory of Station Presets
1 2
Press the SOURCE button to select the radio mode. Press the BAND button repeatedly until the desired radio band is displayed.
11-EN
|
|
|
> |
|
