TIMER OPERATIONS
Adjustments
To switch to monaural FM reception Hold down SHIFT and press TUNER MONO on the remote control so that "MONO" is displayed. To cancel, press again to display "STEREO."
POWER 6STANDBY/ON a/SET SLEEP TIMER TUNER/BAND, AUX, CD SHIFT f,g POWER FUNCTION f,g aSET ENTER
Tip: When FM stereo reception is poor, switching to monaural reduces noise.
To switch the AM tuning interval The default setting of the AM tuning interval is 10 kHz/step. If you use this unit in an area where the frequency allocation system is 9 kHz/step, change the tuning interval. Hold down c and press POWER.
En
Tip: When the AM tuning interval is changed, all preset stations are cleared.
Sleep timer
Turns off the unit automatically after a specified time.
1 Hold down SHIFT and press SLEEP on the remote control.
"SLEEP" is displayed.
Timer playback
Turns on the unit at a specified time for the specified duration. Make sure the clock is set correctly.
1 Press FUNCTION repeatedly to select the desired playback source. 2 Hold down SHIFT and press TIMER.
"5" indicator lights up and "5 PLAY" appears on the display. Then, the timer-on time and the source name appear alternately on the display.
2 Press f or g repeatedly to set the sleep timer duration.
With each press, the timer duration changes in 5-minute steps between 5 to 240 minutes. If there is no button input for 4 seconds, the current setting is entered automatically. The unit turns off after the selected time. To check the remaining time until the unit turns off Hold down SHIFT and press SLEEP on the remote control. The remaining time is displayed for 4 seconds. To cancel the sleep timer Hold down SHIFT and press SLEEP repeatedly on the remote control until "SLEEPoFF" is displayed.
3 Within 7 seconds, press ENTER or a.
The timer-on time and the source name appear alternately on the display.
4 Press f or g to set the timer-on time, then press ENTER or a.
13
|
|
|
> |
|
