Text excerpt from page 11 (click to view)
21. Guide Roller Assembly (Fig. B-21)
1) Remove two screws (A). 2) Remove the Guide Roller From the Base P2/P3 by turning it. NOTE) When disassembling and reassembling: 1 The P2 and P3 Base should not be interchanged.
23. Clutch Assembly T27 (Fig. B-23)
1) Remove the Gear H1 and Arm Assembly Idler. 2) Remove the washer (A). 3) Remove the Clutch Assembly T27.
24. Lever Assembly F/R & Arm F/R (Fig. B-24)
1) 2) 3) 4) Remove the Plate Slider. Remove the washer (A). Remove the Lever Assembly F/R. Remove the Arm Assembly Idler.
22. Clutch Assembly S27 (Fig. B-22)
1) Remove the Gear Cam L/D and the Arm Assembly Idler. 2) Remove the washer (A). 3) Remove the Clutch Assembly S27.
5) Remove the Arm F/R. NOTE) 1) When disassembling the Arm F/R should be horizontal.
