CHAPTER 3 MECHANICAL SYSTEMS
1.1.3 Side Guide Lock
The machine�s size guide is equipped with a side guide to prevent it from opening wider than A4/A3 size (297 mm). If the original is larger than 297 mm, the side guide lock may be disengaged to accommodate an original width of up to 305 mm. 1) Loosen the screw [1], and free the side guide lock [2].
[2] [1]
F03-101-08 Be sure to adjust the side guide to the original before making a copy. Otherwise, the original will tend to move askew.
COPYRIGHT© 2000 CANON INC.
CANON DADF-G1 REV.0 OCT. 2000
3-5
 $4.99 DADF-G1 CANON
Parts Catalog Parts Catalog only. It's available in PDF format. Useful, if Your equipment is broken and You need t…
|
|
|
> |
|
