Sheet attachment positions and procedures of processing the flexible boards/harnesses are shown.
THE METHOD OF ATTACHMENT OF FP-537 FLEXIBLE BOARD
1 Fold dotted line parts of the FP-537 flexible board as shown in figure. Fold Fold 4 Roll the the FP-537 flexible board 1.5 times, in the direction of arrow A.
Adhesive tape Adhesive tape A
Adhesive tape
Fold 5 Put the adhesive sheet and FP-537 flexible board on the hinge assy according to the position of the boss.
2 Pass the FP-537 flexible board through the flexible clamp. Flexible clamp
Boss Adhesive tape
3 Install the flexible clamp in the hinge assy.
Flexible clamp
Hinge assy
DCR-DVD406E/DVD408/DVD408E/DVD506E/DVD508/ DVD508E/DVD808/DVD808E/DVD908/DVD908E_L2
