DCR-TRV40/TRV40E/TRV50/TRV50E
4.
DISCHARGING OF THE FLASHLIGHT POWER SUPPLY CAPACITOR
The power supply capacitor of the flash unit is charged up to the maximum 300V potential. There is a danger of electric shock by this high voltage when the capacitor is handled by hand. The electric shock is caused by the charged voltage which is kept without discharging when the main power of the unit is simply turned off. Therefore, the remaining voltage must be discharged as described below. 4-1. PREPARING THE SHORT JIG To preparing the short jig. a small clip is attached to each end of a resistor of 1k�/1W (1-215-869-11). Wrap insulating tape fully around the reads of the resistor to prevent electric shock.
1 k�/1 W
Wrap insulating tape.
4-2. DISCHARGING THE CAPACITOR 1 Remove the power supply (Battery or AC power adaptor). 2 Open the cassette lid (grip cabinet). 3 Remove the two screws with which the grip cover is fixed. 4 Remove the grip cover. 5 Remove the insulation sheet. 6 Short circuit between 3 and # terminal of the capacitor with the short jig about 10 seconds.
3 Two screws, tapping (M1.7 � 5)
4 Grip cover
5 Insulation sheet
2 Open the cassette lid.
6
Flash unit
Short jig
Power supply capacitor
Note for installing the grip cover When installing the grip cover, insert it in the claws of the grip cabinet.
Two claws
Grip cover
1-2
|
|
|
> |
|
