PIONEER DEH-1950G/XN/ES
Owner's Manual

Section

Operating this unit
# You can also cancel clock settings by holding down AUDIO until the unit turns off.

02
English

Switching the auxiliary setting
It is possible to use auxiliary equipment with this unit. Activate the auxiliary setting when using auxiliary equipment connected to this unit. 1 Press FUNCTION to select AUX.

Turning the clock display on or off
You can turn the clock display on or off. ! Even when the sources are off, the clock display appears on the display. % Press CLOCK to turn the clock display on or off. Each press of CLOCK turns the clock display on or off.
# The clock display disappears temporarily when you perform other operations, but the clock display appears again after 25 seconds.

2 Press a or b to turn the auxiliary setting on or off.

Setting the FM tuning step
The FM tuning step employed by seek tuning can be switched between 100 kHz, the preset step, and 50 kHz. ! If seek tuning is performed in 50 kHz steps, stations may be tuned in imprecisely. Tune in the stations with manual tuning or use seek tuning again. 1 Press FUNCTION to select FM.

2 Press c or d to select the FM tuning step. Press c to select 50 (50 kHz). Press d to select 100 (100 kHz).

Setting the AM tuning step
The AM tuning step can be switched between 9 kHz, the preset step, and 10 kHz. When using the tuner in North, Central or South America, reset the tuning step from 9 kHz (531 kHz to 1 602 kHz allowable) to 10 kHz (530 kHz to 1 640 kHz allowable). 1 Press FUNCTION to select AM.

2 Press c or d to select the AM tuning step. Press c to select 9 (9 kHz). Press d to select 10 (10 kHz).
En

9
