7. GENERAL INFORMATION
7.1 DIAGNOSIS
A
7.1.1 DISASSEMBLY
- Removing the Case (not shown) 1. Remove the Case.
- Removing the CD Mechanism Module (Fig.1)
CD Mechanism Module
1
B
Remove the four screws.
Disconnect the connector and then remove the CD Mechanism Module.
1 1
- Removing the Grille Assy (Fig.1)
2
Release the two latchs and then remove the Grille Assy.
1
C
2
1
2
Grille Assy
- Removing the Tuner Amp Unit (Fig.2)
Fig.1
1
D
Remove the two screws.
2
2
2 3 4
Remove the two screws.
Straighten the tabs at two locations indicated. Remove the two screws and then remove the Tuner Amp Unit.
4 4 1
E
1
3 3
Tuner Amp Unit
Fig.2
F
44
DEH-9/XU/UC
