HHHHHHHHHHHHHH Audio Adjustments
Section
08
Recalling equalizer curves
There are six stored equalizer curves which
you can easily recall at any time. Here is a list of the equalizer curves:
Display SPR-BASS POWERFUL NATURAL VOCAL CUSTOM EQ FLAT Equalizer curve Super bass Powerful Natural Vocal Custom Flat
1 Press AUDIO to select the equalizer curve adjustment. Press AUDIO until EQ-L appears in the display.
English
# If the equalizer band has been previously adjusted, the band of that previously selected will be displayed instead of EQ-L.
2
Press c or d to select the equalizer
band to adjust. Each press of c or d selects equalizer bands in the following order: EQ-L (low)EQ-M (mid)EQ-H (high) 3 Press a or b to adjust the level of the equalizer band. Each press of a or b increases or decreases the level of the equalization band. +6 6 is displayed as the level is increased or decreased.
! CUSTOM is an adjusted equalizer curve that you create. ! A separate CUSTOM curve can be created for each source. (The built-in CD player and the multi-CD player are set to the same equalizer adjustment setting automatically.) If you make adjustments, the equalizer curve settings will be memorized in CUSTOM. ! When EQ FLAT is selected no supplement or correction is made to the sound. This is useful to check the effect of the equalizer curves by switching alternatively between EQ FLAT and a set equalizer curve. % Press EQ to select the equalizer. Press EQ repeatedly to switch between the following equalizer: SPR-BASSPOWERFULNATURAL VOCALCUSTOMEQ FLAT
# You can then select another band and adjust the level. Note If you make adjustments when a curve other than CUSTOM is selected, the newly adjusted curve will replace the previous curve. Then a new curve with CUSTOM appears on the display while selecting the equalizer curve.
Fine adjusting equalizer curve
You can adjust the center frequency and the Q factor (curve characteristics) of each currently selected curve band (EQ-L/EQ-M/EQ-H).
Adjusting equalizer curves
You can adjust the currently selected equalizer curve setting as desired. Adjusted equalizer curve settings are memorized in CUSTOM.
Level (dB) Q=2N Q=2W Center frequency Frequency (Hz)
