Adjusting the surround settings
This adjustment is not possible when Dolby Digital or Pro Logic is turned on for the DHAS680P�s audio output.
Storing the surround settings
Six kinds of parametric EQ adjustment or setting contents can be memorized.
1
1
During playback, press the A.PROC button. The setting menu appears.
During playback, press the A.PROC button. The setting menu appears.
2 2 3
Use the Joystick to select �SURROUND�, then press the ENT button. Use the Joystick to select the surround mode, then press the ENT button. There are six surround modes.
Use the Joystick to select �PRIVATEMEMORY�, then press the ENT button. Use the Joystick to select �WRITE�, then press the ENT button.
FR
3
ES
4 4 5 6 7
Press the ENT button. The level (LV) value turns yellow. Use the Joystick to adjust the level (LV), then press the ENT button. Use the Joystick to select the time (echo time), then press the ENT button. Use the Joystick to adjust the time, then press the ENT button.
NOTE Press the RTN button to return to the previous screen.
Use the Joystick to select the memory location at which you want to store the settings (�PRIVATE-MEMORY 1� to �PRIVATE-MEMORY 6�), then press the ENT button.
DE
IT
NOTE Press the RTN button to return to the previous screen.
8
Press the A.PROC button to close the digital audio processor screen and return to the playback screen.
5
Press the A.PROC button to close the digital audio processor screen and return to the playback screen.
SE
33-EN
|
|
|
> |
|
