MECHANICAL DISASSEMBLY
CAUTION: This LCD TV uses several different kinds of screws. Using the correct screw is necessary to prevent damage. Lead wires must be redressed to their previous locations after servicing.
VHF UHF CATV
TUNER
STAND REMOVAL
Note: Position TV face down on a padded or cushioned surface to protect the screen and finish. Remove 4 screws to take the stand off.
B
B B C/B
CABINET BACK REMOVAL
Remove 8 screws (B : 4X14) to take the cabinet back (C/B) off. Note: The cabinet back can be removed without removing the stand.
B
B B A A STD A A
B B
CABINET BOTTOM REMOVAL
Press 2 hooks inside to remove the cabinet bottom (C/BTM).
Hook
C/BTM
Hook
SHIELD BACK REMOVAL
Remove 6 screws (C: 3X10) to remove the shield back (SH/B).
C
C
C
C SH/B
MOUNTING BRACKET REMOVAL
Remove a screw (D: 3X10) to remove the mounting bracket (M/BRKT).
C C M/BRKT D
