ENGLISH
2
BEFORE USING THE TURNTABLE
Rubber mat � The drive belt is fitted under the platter. When assembling the player, please handle the drive belt with care. � Remove all packing materials attached to the tone arm, except that on the stylus, and then open the dust cover and assemble. Remove the stylus cover after assembling. Hold the platter by the holes at its outer surface, and then carefully lower the platter so that the center spindle enters the center hole. Rotate the platter until one of its outer openings is aligned with the driving roller. (Refer to illustration.) Gently grasp and pull at the ribbon tape of the drive belt that is would under the turntable, and then extend the belt around the driving roller. (After attaching, remove the ribbon tape.) In order to make sure that the drive belt has been correctly fitted, slowly rotate the platter 3 or 4 turns. Place the rubber mat on the platter.
1
2
Spindle
3
Ribbon tape Driving roller Drive belt
IMPORTANT! Please Check.
Check that the drive belt and ribbon tape have been attached under the platter. Grasp the ribbon tape as shown in the illustration to the left, and extend it onto the driving roller.
Equalizer Amplifier switch
This unit has built-in RIAA equalizer amplifier, so it can be connected to an amplifier without PHONO (turntable) input jack. According to the amplifier, set the EQUALIZER AMPLIFIER SWITCH. When the unit is connected to the PHONO (MM) jacks: Rear panel of the amplifier
White
L
Red
R PHONO
ON
OFF
When the unit is connected to the AUX jacks, etc:
Rear panel of the amplifier
White
L
Red
R AUX
ON
OFF
6
|
|
|
> |
|
