DPC-5.2 UPGRADE THE FIRMWARE 1
a. The program for writing b. The program of binary form AAAABBB.bin Two files are saved to the same directory.
AAAA : model name BBB : Version
1. Jigs connection 1-1. PC-JIG Connect the D-Sub(25 pin) cable. 1.2. JIG-DPC-5.2 Connect the FFC and socket (down load PCB). 1.3. Remove a sheet at the bottom. Connect the socket (CP202). 1-4. Turn on the power switch of DPC-5.2. Light up the LED on the JIG PC board assy. 1-5. Start an MS-DOS window. (Click Strat, point to Programs, point to Accessories, and then click MS-DOS Prompt.) Down load JIG Part number 0P42 1-6. Input key the "dvd down AAAABBB.bin" and then click Return.
Main PC board assy (on the bottom side of DPC-5.2)
To Computer
CP202
1 15
Connect the grade up jig Part No. 0P42
c5.2
