Installation 1 Install the lens flexible board with four solders. 2 Referring to the following figure, check each part state of lens rear block. 3 Install Optical Stepping Motor. 4 Tighten one screw. * Tightening torque = 0.049 ± 0.01N � m (0.5 ± 0.1kgf � cm) 4 Screw 3 Optical Stepping Motor 2 Check the state of each part Check if the shaft fits with the groove.
Check if the hook fits with the shaft
1 Solders Lens Rear Block
5 Rotate the gear of lens barrel in arrow direction to extend the lens. 6 Check the inside of lens barrel and the lens for dust or stain, and then install the lens rear block. 7 Tighten three screws. * Tightening torque = 0.049 ± 0.01N � m (0.5 ± 0.1kgf � cm) 8 Install Zoom Gear Block by referring to the installation 4 to 6 in "2-5-1. Zoom Gear Block Replacing Method". 9 Connect the connector of lens flexible board. 0 Assemble the lens flexible board with the mold of Lens Block. qa Engage the lens flexible board with the claw. 7 Screw 9 Connector qa Claw 6 Lens Rear Block
0 Molds
8 Zoom Gear Block
5
DSC-W120/W125_L2 2-10
|
|
|
> |
|
