6-2. Attachment and Removal of P690-SUB Board
1) Remove the two flat screws (2 x 3.5) and raise up the P690-SUB board.
2) Disconnect the FFC joiner of the P690-SUB board from the connector. First, slide the
connector opening with a tweezers or similar tool and then pull out the joiner after loosening the opening.
3) Attachment
is
performed
by
following the reverse procedure of removal. Push in the FFC joiner into the space above the connector while making sure it does not become pinched between the upper case and lower case.
6-3. Removal and Attachment of Laser
Module 1) Remove the FFC joiner from the P690-MAIN board by means of the connector above the laser module. First, slide the connector opening with a tweezers or similar tool, and then pull out the joiner after loosening the opening. 2) Remove the two flat screws (2 x 5 Ni) and then remove the laser module.
Page 11
|
|
|
> |
|
