Listening Mode Setup�Continued
� When the impedance setting for �Front L/R A� or �Front L/R B� in the Speaker Impedance sub-menu is set to �6 ohms� or �4 ohms,� the available options will be �A� and �B.� A (Default): Outputs the source from the speakers connected to the FRONT L/R SPEAKERS A terminals. B: Outputs the source from the speakers connected to the FRONT L/R SPEAKERS B terminals. A+B: Outputs the source from the speakers connected to the FRONT L/R SPEAKERS A and FRONT L/R SPEAKERS B terminals. Note that this option is not available when the front speakers are in Bi-amp or in BTL con�guration. c. Subwoofer This option con�gures the subwoofer to use when playing the source in the Stereo listening mode. Select the terminal to which the subwoofer you want to use is connected. This setting can be made when the �(Speaker A) Subwoofer� is set to an option other than �Not Used� in the Speaker Con�guration sub-menu. However, when the �(Speaker B) Subwoofer� is set to an option other than �Main A� in the Speaker Con�guration sub-menu, the available options will be �A� or �Not Used.� A (Default): Outputs the source only from the subwoofer connected to the SUBWOOFER PRE OUT A terminal. B: Outputs the source only from the subwoofer connected to the SUBWOOFER PRE OUT B terminal. A+B: Outputs the source from the subwoofers connected to the SUBWOOFER PRE OUT A and SUBWOOFER PRE OUT B terminals. Not Used: No subwoofers are used for playback. SPEAKERS B terminals. Note that this option is not available when the front speakers are in Bi-amp or in BTL con�guration. b. Center Speaker This option con�gures the center speaker to use when playing the source in the Direct or Pure Audio listening mode. Select the speaker terminal to which the speaker you want to use is connected. This setting can be made when the �(Speaker B) Center� is set to �Main A� in the Speaker Con�guration sub-menu. � When the impedance setting for �Center A� or �Center B� in the Speaker Impedance sub-menu is set to �6 ohms� or �4 ohms,� the available options will be �A� and �B.� A (Default): Outputs the source from the speaker connected to the CENTER SPEAKERS A terminal. B: Outputs the source from the speaker connected to the CENTER SPEAKERS B terminal. A+B: Outputs the source from the speakers connected to the CENTER SPEAKERS A and CENTER SPEAKERS B terminals. c. Surr L/R Sp This option con�gures the surround speakers to use when playing the source in the Direct or Pure Audio listening mode. Select the speaker terminals to which the speakers you want to use are connected. This setting can be made when the �(Speaker B) Surr L/R� is set to �Main A� in the Speaker Con�guration sub-menu. � When the impedance setting for �Surr L/R A� or �Surr L/R B� in the Speaker Impedance sub-menu is set to �6 ohms� or �4 ohms,� the available options will be �A� and �B.� A (Default): Outputs the source from the speakers connected to the SURR L/R SPEAKERS A terminals. B: Outputs the source from the speakers connected to the SURR L/R SPEAKERS B terminals. A+B: Outputs the source from the speakers connected to the SURR L/R SPEAKERS A and SURR L/R SPEAKERS B terminals. d. Surr Bk Speaker This option con�gures the surround back speakers to use when playing the source in the Direct or Pure Audio listening mode. Select the speaker terminals to which the speakers you want to use are connected. This setting can be made when the �(Speaker B) Surr Back� is set to �Main A� in the Speaker Con�guration sub-menu. However, when the �(Speaker A) Surr Back� is set to �BTL for Front,� �Bi-Amp for Front,� or �Not Used,� this setting will not be displayed. � When the impedance setting for �Surr L/R A� or �Surr L/R B� in the Speaker Impedance sub-menu is set to �6 ohms� or �4 ohms,� the available options will be �A� and �B.�
Direct, Pure Audio Setup Sub-menu
This sub-menu allows you to con�gure the audio effect and playback options when you play a source in the Direct or Pure Audio listening mode. a. Front Speaker This option con�gures the front speakers to use when playing the source in the Direct or Pure Audio listening mode. Select the speaker terminals to which the speakers you want to use are connected. This setting can be made when the �(Speaker B) Front L/R� is set to �Main A� in the Speaker Con�guration sub-menu. � When the impedance setting for �Front L/R A� or �Front L/R B� in the Speaker Impedance sub-menu is set to �6 ohms� or �4 ohms,� the available options will be �A� and �B.� A (Default): Outputs the source from the speakers connected to the FRONT L/R SPEAKERS A terminals. B: Outputs the source from the speakers connected to the FRONT L/R SPEAKERS B terminals. A+B: Outputs the source from the speakers connected to the FRONT L/R SPEAKERS A and FRONT L/R
101
Setup Menu
|
|
|
> |
|
