FOR YOUR INFORMATION _____________________________________________________
The Audio Menu
1 Call up the » Audio« Menu using the blue » o « button.
Audio Menu Track Mode Dig.Output Language
2 von 2 (2ch) Stereo 5.1 Ch English
Note The » Audio« menu informs you about the number of sound tracks (different sound track languages), the various audio modes such as stereo, mono left/right, the number of digital output channels, and the sound track language of the current TV channel.
2 Select the »Track« row using the »,.« buttons then select the desired
sound track »1« or »2« using the »;:« buttons.
3 Select the » Mode« row using the »,.« buttons then select the desired
audio mode »Stereo«, »Mono-Left« or »Mono-Right« using the »; :« buttons. Note: A number of TV stations transmit certain programs with an additional digital sound track. If this is the case you may choose which digital sound track can be heard via a connected digital surround sound amplifier.
4 Select the »Dig. Output« row using the »,.« buttons, then select the
digital output channel, e.g. »5.1 Ch« (= AC 3 digital sound 5.1.Ch) or, e.g. »2 Ch« (= AC 3 digital sound 2.0 Ch) using the »; :« buttons.
5 The »Language« row informs you about the language of the current program. 6 Press the blue » o « button or the »TXT
« button to exit the menu.
26
|
|
|
> |
|
