6-6-7. Manual Adjust 2
Manual Adjust 2 SA.000000 SI.00 EMG.00
0. Jitter 1. Focus 2. Tilt 3. L.F.
Offset Offset Offset
on xx
$
30 DVD_SL 12cm
3. Auto Focus Gain : Adjust focus gain automatically. Adjusted result is reflected on the EEPROM. Execute this with CLVA turned on if possible. If NG, the system will be defective, and repair it. 4. Auto TRK gain : Adjust tracking gain automatically. Adjusted result is reflected on the EEPROM. Execute this with CLVA turned on if possible. If NG, the system will be defective, and repair it. 5. Auto EQ : Adjust RF equalizer properly. Adjusted result is not reflected on the EEPROM. Execute this with CLVA turned on. 6. Auto L.F. Offset : Adjusts electrical offset in ARP. The adjusted value is applied to the EEPROM. During adjustment, lock the CLV. 7. Memorize Pullin : Sets the pull-in level to the EEPROM.
Figure 17
On this screen, manual adjustment can be made where jitter measurement is executed. : Turn on/off jitter measurement. Jitter will not be measured unless the drive runs at CLV. 1. Focus Offset : Adjust focus offset. 2. Tilt Offset : Adjust tilt offset. 3. L.F. Offset : Adjust electrical offset in ARP. 0. Jitter
6-6-9. Check
check SA.000000 SI.00 EMG.00
1. EEPROM Default set 6. EEPROM Data
(set)
6-6-8. Auto Adjust
Auto Adjust SA.000000 SI.00 EMG.00 DVD_SL 12cm
Figure 19
On this screen, various checking can be made. Note, however, that some items such as EEPROM Default set are not recoverable. 1. EEPROM Default set : Use this to set EEPROM set values to default values. Before executing this, it is recommended to record current val6. EEPROM data ues. : Display EEPROM set values list. Display is made with HEX numbers �00� � �FF�.
0. 1. 2. 3. 4. 5. 6. 7.
Auto TRK. Offset Auto Tilt Offset Auto Focus Offset Auto Focus Gain Auto TRK. Gain auto EQ Auto L.F. Offset Memorize Pullin
xx xx
DVD_SL
12cm
Figure 18
On this screen, eacf item can be automaticallyadjusted individually. Note, however, that there are some restriction. 0. Auto TRK Offset : Adjust tracking offset automatically. Adjusted result is reflected on the EEPROM. Turn off tracking with the Focus turned on. Do not execute this at outside track because pickup moves outside. In the case of CD, tracking simple AGC is also adjusted here. 1. Auto Tilt Offset : Adjust tilt offset automatically. Adjusted result is reflected on the EEPROM. Execute this with CLVA turned on. If NG, retry this after focus offset and tangential skew are adjusted. 2. Auto Focus Offset: Adjust focus offset automatically. Adjusted result is reflected on the EEPROM. Execute this with CLVA turned on. If NG, retry this after tilt offset and tangential skew are adjusted.
6-15
|
|
 |
> |
|
