NOTES OF ISO CONNECTOR
1. For VW and Audi vehicles, change the position of fuse installation as shown on the diagram.(Figure 1)
with insulation tape to prevent the risk of short-circuits. (Figure 2) Note: Before cutting the lead wire, disconnect the car battery - (negative) cable.
ISO CONNECTOR type
For other vehicles (initial position) For VW and Audi vehicles
FUSE
Main unit side ISO connector
Figure 1
2. When the car stereo is installed in 1998 and later Volkswagen models, make sure to cut the car lead wire connected the A-5 terminal. (A breakdown could occur if the lead wire is not cut.) After cutting the lead wire, insulate the front end of the lead wire
Figure 2
3. When the Main unit is also connected to an external amplifier, connect REMOTE on the external amplifier to remote turn on lead.
ERROR DISPLAY
If an error occurs, one of the following displays is displayed. Take the measures described below to eliminate the problem.
Mode Error Display
ERROR 2
Cause
Measure
A DISC is caught inside the CD deck and is not ejected. This is a failure of CD deck's mechanism. A DISC cannot be played due to scratches, etc. A DISC is loaded upside-down inside the CD deck and does not play. A CD inside the CD changer is not loaded. A CD inside the CD changer cannot be played due to scratches, etc. A CD inside the CD changer cannot be played because it is loaded upside-down. A DISC inside the DVD changer cannot be played. A DISC cannot be played due to scratches, etc. Replace with a non-scratched, non-warped-disc. Eject the disc then reload it properly.
CD/MP3/ WMA
ERROR 3 ERROR 6
ERROR 2
This is a failure of CD changer�s mechanism. Replace with a non-scratched, non-warped disc.
CD changer
ERROR 3
ERROR 6
Eject the disc then reload it properly.
ERROR 2
This is a failure of DVD mechanism. Retry or replace with a non-scratched, non-warped disc.
DVD changer
ERROR 3
ERROR 6 ERROR P ERROR R
A DISC inside the DVD changer cannot be played because it is loaded upside-down. Parental level error. Region code error.
Eject the disc then reload it properly. Set the correct Parental level. Eject the disc and replace correct region code disc.
If an error display other than the ones described above appears, press the reset button.
Performing a system check
1. Press the [ADJ] button to switch to the adjustment selection display. 2. Press the [ , ] lever upward or downward to select the "SYS CHK <E>". 3. Press and hold the [ ] button for 1 second or longer. "SYSTEM CHK" appears in the display, then the unit returns to the previous operation mode.
ANTI-THEFT INDICATOR
The red Anti-theft indicator is a function for preventing theft. When the DCP is removed from the unit, this indicator blinks. 1. Press the [ADJ] button to switch to thead justment selection display. 2. Press the [ , ] lever upward or downward to select the "BLINK LED". 3. Turn the [ROTARY] knob to select "ON " or "OFF ".
-3-
DXZ558RMP
|
|
|
> |
|
