This is a good quality scan of the original Service Manual from Nordmende, Germany. Contains the circuit diagram, PCB layout, adjust/tune instructions as well. It is NOT in English but in GERMAN language! That was quite right for my german friend from the lower east side in Berlin.
 ;
Received via e-mail this PDF manual is worth the money. This is a quality scan of a manual in excellent condition and is just as good as having the original manual in hand. I have later seen the original manual and it was printed in colour, but this particular manual is black & white but scan resolution is high end quality! All drawings and pictures are presented in great detail. So, nearly perfect score in my opinion.
If you own the turntable you also should own the manual!
Abgleich > Erstellung der Referenzdaten
Hinweis: 1) Schlie�en Sie immer die Skylark-Anschlussvorrichtung an, bevor Sie das Gleichstromkabel an den DVD-Camcorder anschlie�en. Wird die Skylark-Anschlussvorrichtung nach dem Einschalten der Stromversorgung des DVD-Camcorders angeschlossen, kann es zu Fehlbetrieb kommen. 2) Schlie�en Sie die Skylark-Anschlussvorrichtung so an, dass die Leitungsdrähte von der Vorrichtung nach oben weisen.
Lichtkasten
Farbmonitor
30-50cm Frontabschnitt
An VIDEO IN-Buchse
Gelb
Entfernen Sie die Abgleichabdeckung. [Siehe �(1) Abgleichabdeckung� in �5-3 Demontage�.]
AV/S-Ein/ Ausgangskabel Gleichstromkabel Stativ An Netzdose
SKYLARKAnschlussvorrichtung Gleichstromversorgung (5 V/1 A) Rot GND Schwarz (Stift 16) Gelb RS-232C Kabel Schwarz
Netzkabel DZ-ACS1
Personal Computer (PC)
SD RD (Stift 20) (Stift 18)
Wei�
DSP-R-Vorrichtung
Abb. 6-1-1 Anschlüsse für die Erstellung der Referenzdaten
