ELECTRICAL ADJUSTMENT
MAIN C. B
5
1
TP5 (SP�)
4
TP4 (SP+)
TP2 (GND)
2 3
TP1 (FM IF INPUT)
6
1. AM IF Adjustment T2 ................................................................................. 450 kHz 2. AM Freq. Range Adjustment L4 ................................................................................. 515 kHz TC-4 ........................................................................... 1635 kHz 3. AM Tracking Adjustment L1 ................................................................................. 600 kHz TC-1 ........................................................................... 1400 kHz 4. FM IF Adjustment T1 ............................................................................... 107 MHz 5. FM Freq. Range Adjustment L3 .............................................................................. 87.0 MHz TC-3 ........................................................................ 109.0 MHz 6. FM Tracking Adjustment L2 ................................................................................. 90 MHz TC-2 ........................................................................... 106 MHz
