ELECTRICAL PARTS LIST -2/2
� Regarding connectors, they are not stocked as they are not the initial order items. The connectors are available after they are supplied from connector manufacturers upon the order is received.
CHIP RESISTOR PART CODE
Chip Resistor Part Coding
88
A
Resistor Code Value of resistor Chip resistor
Dimensions (mm)
Figure
Wattage 1/16W 1/16W 1/10W 1/8W
Type 1005 1608 2125 3216
Tolerance 5% 5% 5% 5%
Symbol CJ CJ CJ CJ
Form
L W
L 1.0
t
W 0.5 0.8 1.25 1.6
t 0.35 0.45 0.45 0.55
:A Resistor Code : A
104 108 118 128
1.6 2 3.2
-5-
|
|
|
> |
|
