The service was quick and simple, finding the service manual easy and it appears to be the original with colour schematics. It contained the info I was after and so sorted the problem.
I have copied it to CD and attached the envelope to the inside back cover of the owners manual. Good manual and excelent service. Robin Wood, Wood Electronics, New Zealand.
;
Exactly what was needed to assess the product - excellent value and great service
 ;
Nice to have the service manual for the Sony DCR-TRV345E now. The document is of excellent quality.
;
MACKIE HR824 26 pages English-only Service Manual contains:
1) HR824 technical overview with the description of front and rear panel switches.
2) HR824 specs
3) Block Diagram
4) Wiring Diagram
5) Packaging management
6) Spare part & final assembly list (for PCB rev A and B) + exploded view
7) Test Procedures (where, how to measure voltage...) including Test Point diagram on the PCB.
8) IC and Transistor charts.
Excellent guide: very clear, good scan quality enabling us to print readable diagram :-)
Note:
Mackie HR824 make extensive use of surface mount devices (SMD). Service on the HR824 must
only be undertaken by experienced service technicians with the right tools, experience and patience to perform surface mount rework when needed.
;
This Service manual is very well scanned and its clean to read, no any anti-theft words that un-english could understand. I got my CCD600 working with this manual and it´s clear shematics :)
Features
Trinitron technology
GDM-2036S
A superfine aperture grill of 0.3 mm guarantees sharp, well defined colours and maximum brightness. Designed with thin, unbroken vertical openings that allow more electrons to reach the colour phosphors on the screen; images are brighter and colours are more vibrant than those produced by conventional shadow mask systems.
Vertically Flat
The cylindrical , vertically flat screen reduces ambient light reflection and produces crisp, clear and easy to read characters and graphics for pleasing screen images and more vibrant colours than conventional shadow mask systems.
Multiscan Computer Monitor performance
Multiscan monitor performance allows the vertical and horizontal scan frequencies to automatically match your input signal, providing a consistent level of spectacular performance across a wide range of video standards. Multiscan capability provides the added flexibility of upgrade to a higher graphics board standard without changing your monitor.
Digital Control
The GDM2036S features the Sony Display Memory System (SDMS). The monitor has its own digital processor with memory which can control and store critical display parameters. The SDMS includes 9 preset customised display modes for precise adjustment of your visual display. In addition, it contains up to 15 user programmable customised display modes.
|
|
|
> |
|
