I was having a hard time finding the problem with this Mackie 1604 unit. I didn't have a schematic. Went looking on the web and found your site and the price was more then reasonable. Ordered it and within the hour had the manual and within 15 minutes had the unit fixed. Best $4.99 I ever spent. Thank you.
Doug
;
This is a service manual in every sense of the word ( French and German versions of the text are included, as well as English..)
There are explanations of the mechanical and electrical functions, plenty of mechanical drawings, and the needed schematics. The quality of the scanning is excellent - all the component values are clearly legible - and very usefully there are pcb component layouts, so you can find a component on the schematic, and then very quicky pinpoint its physical location on the relevant pcb.
I cannot see how I can give this manual any less than the maximum 5 stars! Great value for money, which will pay for itself immediately. Excellent all round!
;
the manual is great and especially hard to find... thanks for the great service and having a hard to find manuel_
;
Please tell us what you think and share your opinions with others. Be sure to focus your comments on the product. You will receive $2.50 of store credit for Your review.
;
hat alles sehr gut geklappt. Das Servicemaual ist gut zu verwenden. Die Pläne und Schrift
ist klar und leserlich. Außerdem preiswert. Grüße an alle Hifi-Bastler
Features
Trinitron technology
GDM-20SE1VT
A superfine aperture grill of 0.3 mm guarantees sharp, well defined colours and maximum brightness. Designed with thin, unbroken vertical openings that allow more electrons to reach the colour phosphors on the screen; images are brighter and colours are more vibrant than those produced by conventional shadow mask systems.
Digital Multiscan Computer Monitor performance
Multiscan monitor performance allows the vertical and horizontal scan frequencies to automatically match your input signal, providing a consistent level of spectacular performance across a wide range of video standards. Multiscan capability provides the added flexibility of upgrade to a higher graphics board standard without changing your monitor. Digital multiscan is the system within the monitor that uses an internal CPU and ASIC to correct image distortion. responding to incoming video frequency and quickly performs all necessary adjustments, so distortion free images appear automatically, at any given resolution.
Low Radiation Standards
Complies with TCO92 low emmisions regulations with TUV ergonomics mark.
TCO92 and Energy Star Power Management
Sony remains committed to a policy of enviromental and ergonomic safety. The Multiscan 20SE1VT complies fully with the EPA�s (USA environmental Protection Agency) power management guidelines, and even with stricter guidelines as laid down by TCO92 specifications.
Advanced Colour temp control
The colour temperature can be adjusted using the digital controls. The multiscan 20SE1VT offers variable color temperature settings of 5000/6500 and 9300 degrees Kelvin, the 3 color temperatures most frequently used to simulate various enviromental and lighting conditions. The user mode permits virtually unlimited color adjustment through changing the presets, Hue, saturation and intensity (HSI).
|
|
|
> |
|
